10.12 Error Behavior (Watchdog)
10.12.1 Behavior of Outputs
In case of a failure of the Modbus communication, the outputs’ behavior is as follows, depending on
the defined time for the Watchdog (register 0x1120, page 54):
 Watchdog = 0 ms (default)
 outputs hold the momentary value in case of an error
 Watchdog > 0 ms
 outputs switch to
0 after the watchdog time has expired (setting in register 0×1120).
10.12.2 Behavior of the BUS LED
If the Watchdog has tripped, the BUS LED behaves as follows:
10.13 Parameters and Diagnostic Messages of the I/O Channels
NOTE
Setting the outputs to predefined substitute values is not possible in Modbus TCP. Even-
tually parameterized substitute values will not be used.
Watchdog BUS-LED
tripped constantly red
NOTE
Please find explanations regarding parameters and diagnostic messages in the section
Register Mapping of the TBEN-L Devices, page 57.
