turck TBEN-L Series User Manual

EtherNet/IP™
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
70
11.6 EtherNet/IP™ Standard Classes
The TBEN-L stations support the following EtherNet/IP™ Standard Classes in accordance with the
CIP specification.
11.6.1 Identity Object (0x01)
The following description of the Ethernet Link Object is taken from the CIP specification, Vol. 2, Rev.
2.1 by ODVA & ControlNet International Ltd. and adapted to TBEN-L.
Class Attributes
Instance Attributes
Class Code Object name
01 (0x01) Identity Object (0x01)
04 (0x04) Assembly Object (0x04)
06 (0x06) Connection Manager Object (0x06)
245 (0xF5) TCP/IP Interface Object (0xF5)
246 (0xF6) Ethernet Link Object (0xF6)
Attr. No. Attribute name Get/
Set
Type Value
1 (0x01) REVISION G UINT 1
2 (0x02) MAX OBJECT INSTANCE G UINT 1
6 (0x06) MAX CLASS ATTRIBUTE G UINT 7
7 (0x07) MAX INSTANCE ATTRIBUTE G UINT 7
Attr. No. Attribute name Get/
Set
Type Description
1 (0x01) VENDOR G UINT Contains the vendor ID.
TURCK = 48
2 (0x02) PRODUCT TYPE G UINT Shows the general product type.
Communications Adapter
12
dec
= 0x0C
3 (0x03) PRODUCT CODE G UINT Identifier for a specific product of a device
type.
default: 27247
dec
= 6A6F
4 (0x04) REVISION
Major Minor
G STRUCT
OF:
USINT
USINT
Revision of the item the Identity Object is rep-
resenting.
0x01
0x06
