71
2017/06
Device Status
Common Services
11.6.2 Assembly Object (0x04)
Assembly Objects bind attributes of multiple objects to allow data to or from each object to be sent
or received over a single connection.
The following description of the Ethernet Link Object is taken from the CIP specification, Vol. 2, Rev.
2.1 by ODVA & ControlNet International Ltd. and adapted to TBEN-L.
Class Attributes
5 (0x05) DEVICE STATUS G WORD See page 71
6 (0x06) SERIAL NUMBER G UDINT Contains the ident-no. of the product (3 last
bytes of the MAC-ID).
7 (0x07) PRODUCT NAME
LENGTH
NAME
G STRUCT
OF:
USINT
STRING
[13]
e. g.:
TBEN-L5-16DXP
Bit Name Definition
0 to 1 reserved default = 0
2 Configured TRUE = 1
The application of the device has been configured (
default-settings).
3 reserved default = 0
4 to 7 Extended Device Sta-
tus
0011 = no I/O connection established
0110 = at least one I/O connection in run mode
0111 = at least one I/O connection established, all in IDLE
mode
All other settings = reserved
8 to 15 reserved default = 0
Service code
Class
Instance Service name
01 (0x01) yes yes Get_Attribute_All
Returns a predefined list of the object‘s attributes.
05 (0x05) no yes Reset
Starts the reset service for the device.
14 (0x0E) yes yes Get_Attribute_Single
Returns the contents of a specified attribute.
16 (0x10) no no Set_Attribute_Single
Modifies a single attribute.
Attr. No. Attribute name Get/
Set
Type Value
1 (0x01) REVISION G UINT 2
2 (0x02) MAX OBJECT INSTANCE G UINT 104
