Instance Attributes
Common Services
Configuration Assembly
TBEN-L stations support Configuration Assembly. It enables an EDS-based configuration/parame-
terization of the devices in the PLC software (if supported by the PLC).
Instance 106
The Configuration Assembly contains:
10 byte configuration data
+ x byte parameter data of the respective device
Attr. No. Attribute name Get
/
Set
Type Description
3 (0x03) DATA S ARRAY OF
BYTE
4 (0x04) SIZE G UINT Number of bytes in attr. 3
256 or variable
Service code
Class
Instance Service name
01 (0x01) yes yes Get_Attribute_All
14 (0x0E) no yes Get_Attribute_Single
Configuration Assembly
Module Standard bytes Module specific
parameter data
total
TBEN-Lx-16DIP/
TBEN-L4-16DIN
10 byte 21 byte 31
TBEN-Lx-16DOP/
TBEN-L4-16DON
10 byte 4 byte 14
TBEN-Lx-8DIP-8DOP 10 byte 16 byte 26
TBEN-Lx-16DXP/
TBEN-L4-16DXN
10 byte 26 byte 36
