Device Characteristics
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
36
8.3 TBEN-Lx-16DIP/TBEN-L4-16DIN
TBEN-Lx-16DIP offers sixteen digital inputs for 3-wire PNP sensors.
TBEN-Lx-16DIN offers sixteen digital inputs for 3-wire NPN sensors.
8.3.1 Technical Data
8.3.2 Wiring Diagram
 Connecting the Devices to Ethernet, page 27
 Connect Power Supply, page 28
 Connecting Digital Sensors and Actuators, page 30
power supply
Nominal value 24 V DC from operating voltage
Permissible range 18 … 30 V DC
Operational current (from V
1
) < 150 mA
Sensor/actuator supply VAUX
1
Supply connector C0-C7 from V1
120 mA per connector, short-circuit proof
Digital inputs
Number of channels 16
Input type
– TBEN-Lx-16DIP PNP
– TBEN-L4-16DIN NPN
Switching threshold EN 61131-2 type 3, PNP or NPN
Signal voltage, low level < 5 V
High level signal voltage > 11 V
Low level signal current < 1.5 mA
High level signal current > 2 mA
Switch-on delay 2.5 ms
Type of input diagnosis channel diagnostics
Potential isolation galvanic isolation to the field bus
