Mounting
Mounting 2 mounting holes, ? 6.3 mm
Mounting distance device to device 50 mm
Valid for operation in the ambient temperatures men-
tioned below, with sufficient ventilation as well as max-
imum load (horizontal mounting).
At low simultaneity factors and low ambient tempera-
tures, mounting distances of < 50 mm may be possible.
Tests
Vibration test according to EN 60068-2-6/ IEC 68-2-47,
acceleration up to 20 g
Drop and topple according to IEC 60068-2-31/IEC 60068-2-32 1
Shock test according to EN 60068-2-27
EMC according to EN 61131-2
Ambient conditions
Temperature range
– Operating temperature - 40 °C to + 70 °C
– Storage/transport - 40 °C to + 85°C
Operating altitude max. 5000 m
Protection class
IP65/IP67/IP69K
Housing
Size 60.4 × 230.4 × 24 mm (w × l ×h)
Material Fibre-glass reinforced Polyamide (PA6-GF30)
Window material Lexan
Screw material 303 Stainless Steel
halogen-free yes
