turck TBEN-L Series User Manual

Device Characteristics
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
42
8.6 TBEN-Lx-16DXP/TBEN-L4-16DXN
The device provides sixteen channels, which can be configured individually, depending on the spe-
cific application requirements.
Up to sixteen 3-wire PNP sensors or sixteen DC actuators can be connected to TBEN-Lx-16DXP.
Up to sixteen 3-wire NPN sensors or sixteen DC actuators can be connected to TBEN-L4-16DXN.
8.6.1 Technical Data
power supply
Nominal value 24 V DC from operating voltage
Permissible range 18 … 30 V DC
Operating current < 150 mA
Sensor/actuator supply V
AUX1
/V
AUX2
supply of connectors
C0 - C3 from V1
C4 - C7 from V2
120 mA per connector, short-circuit proof
Digital inputs
Number of channels 16
Input type
– TBEN-Lx-16DXP PNP
– TBEN-L4-16DXN NPN
Switching threshold EN 61131-2 type 3, PNP or NPN
Signal voltage, low level < 5 V
High level signal voltage > 11 V
Low level signal current < 1.5 mA
High level signal current > 2 mA
Input resistance 4 k
Switch-on delay 2.5 ms
Input frequency 100 Hz
Type of input diagnostics channel diagnostics
Digital outputs
Number of channels 16, DC actuators
Output type
– TBEN-Lx-16DXP PNP
– TBEN-L4-16DXN NPN
Output voltage 24 VDC from potential group
Output current per channel
– TBEN-Lx-16DXP 2 A, short-circuit proof, max. 2 A per connector
– TBEN-L4-16DXN 1 A, short-circuit proof, max. 2 A per connector
Load type ohmic, inductive, lamp load
Simultaneity factor 0.56 for entire module,
total current max. 9 A per module
Type of output diagnostics channel diagnosis
Potential isolation galvanic isolation to the field bus
