23
2017/06
6M
o
u
n
t
i
n
g
The devices must be attached
to a level, pr
e-drilled and grounded mounting surface.
Attach the module to the moun
ting surface with two M6 sc
rews. The maximum tightenin
g
torque for the screws is 1.5 Nm.
Fig. 4: Attaching the devic
e to the mounting plate
218 [5.58]
M6 (2x)
max. 1.5 Nm
24
