Device Characteristics
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
38
8.4 TBEN-Lx-16DOP/TBEN-L4-16DON
TBEN-Lx-16DOP offers sixteen digital PNP outputs for DC actuators.
TBEN-Lx-16DON offers sixteen digital NPN outputs for DC actuators.
8.4.1 Technical Data
8.4.2 Wiring Diagram
Connecting the Devices to Ethernet, page 27
Connect Power Supply, page 28
Connecting Digital Sensors and Actuators, page 30
power supply 24 V DC from operating voltage
Nominal value
Permissible range 18 … 30 V DC
Operational current (from V
1
) < 150 mA
Sensor/actuator supply VAUX
2
Supply connector C0-C7 from V2
120 mA per connector, short-circuit proof
Digital outputs
Number of channels 16
Output type
– TBEN-Lx-16DOP PNP
– TBEN-L4-16DON NPN
Output voltage 24 VDC from potential group
Output current per channel
– TBEN-Lx-16DOP 2 A, short-circuit proof, max. 2 A per connector
– TBEN-L4-16DON 1 A, short-circuit proof, max. 2 A per connector
Load type ohmic, inductive, lamp load
Simultaneity factor 0.28 for entire module,
total current max. 9 A per module
Type of output diagnostics channel diagnosis
Potential isolation galvanic isolation to the field bus
