EtherNet/IP™
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
84
Meaning of the Process Data Bits
11.6.4 Connection Manager Object (0x06)
This object is used for connection and connectionless communications, including establishing con-
nections across multiple subnets.
The following description of the Ethernet Link Object is taken from the CIP specification, Vol. 2, Rev.
2.1 by ODVA & ControlNet International Ltd. and adapted to TBEN-L.
Common Services
Name Meaning
I/O data
DIx DI = digital input
DOx DO = digital output
Cx C = connector
Px P = pin
Diagnostics
DiagWarn See VSC 100, attr. 109 (0x6D), Status register 2, page 92
V
2
V
1
COM
CFG
FCE
I/O Diag Group diagnostics of in-/outputs
SchedDiag The mapping of input and output diagnostics is
activated
SCSx Overcurrent at sensor supply of the respective connector
SCOx Overcurrent at output
Service code
Class
Instance Service name
84 (0x54) no yes FWD_OPEN_CMD
(Opens a connection)
78 (0x4E) no yes FWD_CLOSE_CMD
(Closes a connection)
82 (0x52) no yes UNCONNECTED_SEND_CMD
