EtherNet/IP™
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
92
Object Instance 2
Attr. No.
dec.
(hex.)
Attribute name Get/
Set
Type Description
109
(0x6D)
Status register 2 G STRUCT The Status Word contains general station
status information,
Device
– Bit 15: reserved
– Bit 14: "Force Mode Active Error" The
Force Mode is activated (FCE).
– Bit 13: reserved
– Bit 12: reserved
Internal bus
– Bit 11: "I/O Cfg Modified Error" (CFG)
Configuration error
– Bit 10: "I/O Communication Lost Error"
(COM)
Internal communication disturbed
Voltage errors
– Bit 09: "V1 too low"
V1 < 18 V DC
– Bit 08: reserved
– Bit 07: "V2 too low"
V2 < 18 V DC
– Bit 06: reserved
– Bit 05: reserved
– Bit 04: reserved
Warnings
– Bit 03: reserved
– Bit 02: reserved
– Bit 01: reserved
– Bit 00: "I/O Diags Active Warning"
(DiagnWarn) At least one I/O-channel
sends active diagnostics.
115
(0x73)
ON IO
CONNECTION
TIMEOUT
G/S ENUM
USINT
Reaction to the I/O connection exceeding
the time limit.
SWITCH IO FAULTED (0):
The channels are switched to substitute
value.
SWITCH IO OFF (1):
The outputs are switched to 0.
SWITCH IO HOLD (2):
No further changes to the I/O-data. The
outputs are held.
