11.6.5 TCP/IP Interface Object (0xF5)
The following description of the Ethernet Link Object is taken from the CIP specification, Vol. 2, Rev.
1.1 by ODVA & ControlNet International Ltd. and adapted to TBEN-L.
Class Attributes
Instance Attributes
Attr. No. Attribute name Get/
Set
Type Value
1 (0x01) REVISION G UINT 1
2 (0x02) MAX OBJECT INSTANCE G UINT 1
3 (0x03) NUMBER OF INSTANCES G UINT 1
6 (0x06) MAX CLASS IDENTIFIER G UINT 7
7 (0x07) MAX INSTANCE ATTRIBUTE G UINT 6
Attr. No. Attribute name Get/
Set
Type Description
1 (0x01) STATUS G DWORD Interface status (siehe page 86)
2 (0x02) CONFIGURATION
CAPABILITY
G DWORD Interface Capability Flag (siehe page 86)
3 (0x03) CONFIGURATION
CONTROL
G/S DWORD Interface Control Flag (siehe page 86)
4 (0x04) PHYSICAL LINK
OBJECT
G STRUCT
Path size
UINT Number of 16 bit words: 0x02
Path:
Padded
EPATH
0x20, 0xF6, 0x24, 0x01
5 (0x05) INTERFACE CON-
FIGURATION
G Structure
of:
TCP/IP Network Interface Configuration
(siehe page 86)
IP address G UDINT Actual IP address
NETWORK MASK G UDINT Actual network mask
GATEWAY ADDR. G UDINT Actual default gateway
NAME SERVER G UDINT 0 = no server address configured
NAME SERVER 2 UDINT 0 = no secondary server address configured
DOMAIN NAME G UDINT 0 = no Domain Name configured
6 (0x06) HOST NAME G STRING 0 = no Host Name configured (siehe
page 87)
12 (0x0C) Quick Connect G/S BOOL 0 = deactivate
1 = activate
