turck TBEN-L Series User Manual

EtherNet/IP™
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
86
Common Services
 Interface Status
The Status attribute indicates the status of the TCP/IP network interface.
Refer to the state diagram,Fig. 16: TCP/IP object state diagram (acc. to CIP Spec., Vol.2, Rev.
1.1)
for a description of object states as they relate to the Status attribute.
 Configuration Capability
The Configuration Capability indicates the device’s support for optional network configuration
capability.
 Configuration Control
The Configuration Control attribute is used to control network configuration options.
Service code
Class
Instance Service name
01 (0x01) yes yes Get_Attribute_All
02 (0x02) no no Set_Attribute_All
14 (0x0E) yes yes Get_Attribute_Single
16 (0x10) no yes Set_Attribute_Single
Bit(s) Name Definition
0-3 Interface Configuration
Status
Indicates the status of the Interface Configuration attribute:
0 = The Interface Configuration attribute has not been configured
1 = The Interface Configuration attribute contains valid configura-
tion.
2 to 15: reserved
4 to 31 reserved
Bit(s) Name Definition Value
0 BOOTP Client The device is capable of obtaining its net-
work configuration via BOOTP.
1
1 DNS Client The device is capable of resolving host
names by querying a DNS server.
0
2 DHCP Client The device is capable of obtaining its net-
work configuration via DHCP.
1
Bit(s) Name Definition
0-3 Startup-
Configuration
Determines how the device shall obtain its initial configuration.
0 = The device shall use the interface configuration values previ-
ously stored (for example, in non-volatile memory or via hardware
switches, etc).
1 to 3: reserved
4 DNS Enable Always 0
5-31 reserved Set to 0
