turck TBEN-L Series User Manual

Device Characteristics
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
34
8.2 General Technical Data
Supply voltage
V1 (incl. electronics supply) 24 V DC
Permissible range
18 … 30 V DC
V2 24 V DC
Permissible range
18 … 30 V DC
Potential isolation Galvanic isolation of V1 and V2
Connectors
Ethernet 2 x M12-connector (OUT), 4-pole, D-coded
power supply
– TBEN-L4 7/8" connector, 4-pole
– TBEN-L5 7/8" connector, 5-pole
In-/outputs M12 connector, 5-pole
Permissible torques
– Ethernet 0.6 Nm
– I/O channels/supply. 0.8 Nm
– Mounting (M6 screws) 1.5 Nm
– Protective cap 0.5 Nm
Isolation voltages
V1 to V2 500 V AC
V1/V2 to the field bus 500 V AC
Protocol properties
Modbus TCP
Address assignment
Static IP (rotary coding switches), BOOTP, DHCP
Supported Function Codes
FC1, FC2, FC3, FC4, FC5, FC6, FC15, FC16, FC23
Number of connections
8
EtherNet/IP™
Address assignment
according to EtherNet/IP™ standard
Quick Connect (QC)
< 150 ms
Device Level Ring (DLR)
supported
Number of connections
3
PROFINET
Address assignment
DCP
MinCycleTime
1 ms
Fast Start-Up (FSU)
< 150 ms
Diagnostics
according to PROFINET Alarm Handling
Topology detection
supported
Automatic address assignment
supported
Media Redundancy Protocol (MRP)
supported
