11.7.3 Process Data Class (VSC102)
This class contains the process-relevant information.
Class Instance
Object instance 1, standard output process data (compressed)
This instance is not supported.
Object instance 2, standard output process data (compressed)
This instance is not supported.
Object Instance 3, diagnostic instance
138
(0x8A)
GW Status
Register
Get/set DWORD Activates or deactivates the mapping of
the status word into the device's input
data.
139
(0x8B)
GW Control Regis-
ter
Get/set DWORD Activates or deactivates the mapping of
the status word into the device's input
data.
140
(0x8C)
Disable Protocols Get/set UINT Deactivation of the used Ethernet proto-
col.
bit assignment
Bit 0 = EtherNet/IP™ (can not be disabled
via EtherNet/IP™-interface)
Bit 1 = Modbus/TCP
Bit 2 = PROFINET
Bit 3 - 14 = reserved
Bit 15 = web server
NOTE
Please refer to section Class Instance of the VSCs, page 90 for the description of the class
instance for the VSC.
Attr. No.
dec. (hex.)
Attribute name
Get/
Set
Type Description
104 (0x68) GW
Summarized
diagnostics)
G/S BOOL 0 = inactive
1 = active: 1 bit of diagnosis mapped at the
end of the input data image (
page 67).
Changes become valid after a start-up!
105 (0x69) GW
scheduled diag-
nostics (manufac-
turer specific
diagnostics)
G/S BOOL 0 = inactive
1 = activated: Used for activating the map-
ping of the channel-specific diagnostic
bits into the process input data (
page 67).
Changes become valid after a start-up!
106 (0x6A) reserved -
Attr. No.
dec.
(hex.)
Attribute name Get/
Set
Type Description
