12.6.2 Description of the Acyclic I/O-Channel User Data
45044
(0xAFF4)
I&M4-functions STRING
[54]
45045
(0xAFF5) to
45055
(0xAFFF)
I&M5 to I&M15-functions not supported
0x7000 Station parameters WORD r/w Activate active field bus protocol
Index
(dec.)
Name Data type r/w Comment
1 Device parameters specific r/w Device parameters
2 Module type ENUM
UINT8
r Contains the device type
3 Module version UINT8 r Firmware version of the I/O-channels
4 Module ID DWORD r Ident number of the I/Os
5 to 9 reserved
10 Slave controller version UINT8
array [8]
r Version no. of the slave
controller
11 to 18 reserved
19 Input data specific r Input data of the respective
I/O channel
20 to 22 reserved
23 Output data specific r/w Output data of the respective I/O
channel
Index
(dec.)
Name Data type r/w Comment
