41
2017/06
8.5.3 Parameters for I/O Channels
Further information about parameters can be found in the fieldbus specific chapters.
EtherNet/IP™: Digital Versatile Module Class (VSC117), page 95 ff.
Modbus TCP: Register Mapping of the TBEN-L Devices, page 57 ff.
PROFINET: Parameters, page 107
8.5.4 Diagnostic Messages
Further information about the diagnostic data mapping can be found in the fieldbus specific chap-
ters.
Modbus TCP: Register Mapping of the TBEN-L Devices, page 57 ff.
EtherNet/IP™: Digital Versatile Module Class (VSC117), page 95 ff.
PROFINET: PROFINET-diagnostics, page 103
Parameter name Value Description
Digital input
Invert digital input (Inv. DIx)
0 = no A
1 = yes Inverts the digital input signal.
Pulse stretching
input
0 - 255 The input signal is stretched to a time between
10 to 2550 ms.
Default setting:
0 = pulse stretching deactivated
(standard pulse = 2,5 ms)
Example:
10 = pulse of 100 ms
Manual output reset
after overcurrent
(SROx)
0 = no The output switches on automatically after an
overload.
1 = yes The output is manually switched-off after an
overload until a new set-command is given
(rise and fall).
Diagnostics Description
SCSx Short-circuit at the supply voltage for the respective connector.
SCOx Overcurrent at the respective output
