The following table shows the register mapping for the different Modbus addressing methods:
0x2400 ro V1 [mV]: 0 at < 18 V
0x2401 ro V2 [mV]: 0 at < 18 V
0x8000 to 0x8400 ro Process data inputs (32 registers per device)
0x9000 to 0x9400 rw Process data outputs (32 registers per device)
0xA000 to 0xA400 ro Diagnostics (32 registers per device)
0xB000 to 0xB400 rw Parameters (32 registers per device)
Description Hex Decimal 5-digit Modicon
Packed inputs 0x0000
to
0x01FF
0
to
511
40001
to
40512
400001
to
400512
Packed outputs 0x0800
to
0x09FF
2048
to
2549
42049
to
42560
402049
to
402560
Station Identifier 0x1000
to
0x1006
4096
to
4102
44097
to
44103
404097
to
404103
Module status 0x100C 4108 44109 404109
Process image length in bit for the digital
output modules
0x1012 4114 44115 404115
process image length in bit for the digital
input modules
0x1013 4115 44116 404116
watchdog, actual time 0x1020 4128 44129 404129
watchdog, predefined time 0x1120 4384 44385 404385
Modbus connection mode register 0x1130 4400 44401 404401
Modbus connection timeout in sec. 0x1131 4401 44402 404402
Modbus parameter restore, 0x113C to
0x113D
4412 to
4413
44413 to
44414
404413 to
404414
Modbus parameter save, 0x113E to
0x113F
4414 to
4415
44415 to
44416
404415 to
404416
Deactivate protocol 0x1140 4416 44417 404417
Active protocol 0x1141 4417 44418 404418
LED behavior (PWR) at
V2 undervoltage
0x1150 4432 44433 404433
V1 [mV]: 0x2400 9216 49217 409217
V2 [mV]: 0x2401 9217 49218 409218
Process data inputs
(32 registers per device)
0x8000 to
0x8400
32768 to
32792
– 432769 to
432793
Address (hex.) Access
ro = read only
rw = read/
write
Description
