turck TBEN-L Series User Manual

EtherNet/IP™
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
96
Input data
113 (0x71) Module input_1 G DWORD Input data of the respective I/Os.
114 (0x72) Module input_2 G DWORD Input data of the respective I/Os.
Output data
115 (0x73) Module output_1 G DWORD Output data of the respective I/Os.
116 (0x74) Module output_2 G DWORD Output data of the respective I/Os.
...
Diagnostics
119 (0x77) Short circuit output
error_1
G DWORD Overcurrent at output
120 (0x78) Short circuit output
error_2
G DWORD Overcurrent at output
121 (0x79) Short circuit V
AUX
error_1
G DWORD Overcurrent at sensor/actuator supply
122 (0x7A) Short circuit V
AUX
error_2
G DWORD Overcurrent at sensor/actuator supply
...
Parameter data
127 (0x7F) Invert input data_1 G/S DWORD The input signal is inverted (channel 0 to
15).
...
133 (0x85) Auto recovery out-
put_1,
G/S DWORD The outputs switch on automatically after
an overload (output 0 to 15).
...
137 (0x89) Re-triggered
recovery output_1
G/S DWORD The outputs (channel 0 to 15) have to be
re-triggered in case of an overload.
...
139 (0x8b) Enable high side
output driver_1
G/S DWORD Enables the high side output driver of
channels (channel 0 to 15).
...
149 (0x95)
to
164 (0xA4)
Pulse stretching
input x
G/S Byte The input signal is stretched to a time
between 10 to 2550 ms.
Default setting:
0 = pulse stretching deactivated
(standard signal = 2,5 ms)
Example:
10 = signal of 100 ms
Attr. No.
dec.
(hex.)
Attribute name Get/
Set
Type Description
