Blinking icon: The battery is low. (If the AC adapter is
connected while the icon is blinking, the battery is
incorrectly installed, is the wrong type, or has gone
bad.)
Channel info icon This icon has several available states:
● P25: The received signal is digitized voice
(APCO P25)
● LNK: The current channel is configured as a
voice channel, but the scanner is receiving data
on it.
● DAT: The current channel is configured as a
control channel, and the scanner is receiving
data on it.
● ENC: The received signal is encrypted P25
digitized voice, and the scanner has muted the
audio.
● Cxx.x: The scanner has detected a CTCSS
code; the received code is displayed in place of
the Xs.
● DCSxxx: The scanner has detected a DCS code;
the received code is displayed in place of the
Xs.
● NAC:xxx: The scanner has detected a P25
network address code (NAC); the received code
is displayed in place of the Xs.
Close call icon Normal (open) icon:
● Steady: Close call priority mode is on.
● Blinking: Close Call Only mode is on, or the
scanner has detected a close call signal.
