Wired Clone
This feature allows you to copy all the settings from one scanner to another of the same
model:
1. Use one of the included data cables to connect the two scanners. Plug the DB9
end into the rear port of one scanner and the other end into the front port of the
other scanner.
2. On the scanner you want to copy from, go to the Wired Clone menu and select
Master then select the port (Front Port or Rear Port) that the cable is connected
to on that scanner .
3. On the scanner you want to copy to, go to the Wired Clone menu and select Slave
then select the port (Front Port or Rear Port) that the cable is connected to on
that scanner .
The master scanner checks to make sure the slave is properly connected and ready to
receive, then begins the data transfer. Do not disconnect the data cable or turn off
either scanner during the transfer.
When the transfer is finished, both scanners display a Complete message. Reboot the
slave scanner to load the new settings.
All settings and data saved on the Slave scanner will be erased!
This page applies to the following scanner(s): BCD996XT BCT15X Users
Guide
