Each block is assigned a size code based on the way the control channel sends the TGID
data. Note that codes 12, 13, and 14 take up more than one block:
Size
Code
Fleet / SubFleet? /
ID
Number of Blocks
Needed
0 (as Type II ID) 1
1 128 / 4 / 16 1
2 16 / 8 / 64 1
3 8 / 8 / 128 1
4 1 / 16 / 512 1
5 64 / 4 / 32 1
6 32 / 8 / 32 1
7 32 / 4 / 64 1
8 16 / 4 / 128 1
9 8 / 4 / 256 1
10 4 / 8 / 256 1
11 2 / 16 / 256 1
12 1 / 16 / 1024 2
13 1 / 16 / 2048 4
14 1 / 16 / 4096 8
This page applies to the following scanner(s): BCD996XT BCT15X BCD396XT
BC346XT Users Guide
file:///C|/Documents%20and%20Settings/POpitz/My%20Do...ts/temp/CDImage_090515/Manual/MotorolaFleetMaps.html (4 of 4)5/26/2009 11:15:52 AM
