24.SPECIFICATIONS
114
24. SPECIFICATIONS
24-1. Analog Section
Sensor excitation 10V, 5V, 2.5V DC (digital adjustment)
Output current: Within 120mA
4-wire (Up to four 350Ωload cells can be connected.)
Signal input range -3.0 - +3.0mV/V
Zero and gain adjustment Performed by digital computation
Accuracy Non-linearity Within 0.02%FS ± 1 digit (at a 3.0mV/V
input)
Zero drift Within 0.5μV/ RTI
Gain drift Within 0.01%/
A/D converter Rate 2000 times/sec.
Resolution 16 bits (binary)
Analog filter 10Hz, 30Hz, 100Hz, 300Hz (digital adjustment)
Analog voltage output Output level Approx. 2V per 1mV/V of input Load
resistance 2KΩ or more
24-2. Digital Section
Display STN color LCD module (display area: 75mm × 56mm)
320 × 240 dots
Indicated value: ± 99999 (5-digit)
Equivalent input calibration Range: 0.5 - 3.0mV/V Error: Within ± 0.1%FS
Hold functions 1) Sample hold
2) Peak hold
3) Valley hold
4) Peak-to-peak hold
5) Relative maximum hold
6) Relative minimum hold
7) Inflection point hold
Period setting (all period, external signal, time, time with
trigger) is available for 2) - 4).
Combinations allow selection from 16 hold types.
