13.RS-232C INTERFACE
81
13. RS-232C INTERFACE
The RS-232C is an interface to read the indicated value and status of the F371 and to
write parameters into the F371.
This interface is convenient to process controls, totals, records, etc., by connecting the
F371 to a computer, process controller, sequencer or the like.
13-1. Communication Specifications
13-1-1. Specifications
Signal level ：Based on RS-232C
Transmitting distance：Approx.15m
Transmitting method ：Asynchronous，Full duplex
Transmitting speed ：1200，2400，4800，9600 or 19200bps Selectable
Bit configuration ：Start bit 1
Character length 7 or 8 bit Selectable
Stop bit 1 or 2 bit Selectable
Parity Parity none，odd or even Selectable
Terminator CR，CR+LF Selectable
Code ：ASCII
