14.BCD DATA OUTPUT(OPTION)
92
14. BCD DATA OUTPUT(OPTION)
The BCD data output is an interface to extract the indicated value of the F371 as BCD
data. This interface is convenient to process controls, totals, records, etc., by connecting
the F371 to a computer, process controller, sequencer or the like.
The I/O and internal circuits are electrically insulated by photocoupler.
The data output rate can be selected from once/sec., 10 times/sec., 100 times/sec., and
1000 times/sec.
14-1. Connector Pin Assignment
Anphenol Connector（36-Pin）
Compatible connector is DDK57-30360 or equivalent.
No. Signal No. Signal
1
＊
COM 19
＊
COM
2 Out 1 20 Out 20000
3 Out 2 21 Out 40000
4 Out 4 22 Out 80000
5 Out 8 23 Out Minus(Polarity)
6 Out 10 24 Out OVER
7 Out 20 25 Out
P.C（Stable）
8 Out 40 26 Out STROBE
9 Out 80 27 In
BCD Data Hold
10 Out 100 28 In Logic Switching
11 Out 200 29
12 Out 400 30
13 Out 800 31
14 Out 1000 32
15 Out 2000 33
16 Out 4000 34
17 Out 8000 35
18 Out 10000 36
To Next Page
