24.SPECIFICATIONS
115
Comparison functions
External output
HI-HI limit HH
LO-LO limit LL
OK
HI limit HI
LO limit LO
Calibration value selection Four calibration values can be stored in memory and
switched.
24-3. Communication
RS-232C communication interface
Start/stop system
Baud rate: 1200bps - 19200bps
24-4. Options
BCD data output Open-collector output
Output rate
Can be selected from 1 time/sec., 10 times/sec., 100 times/sec.
and 1000 times/sec.
RS-485 communication interface
Communication conditions are the same as RS-232C.
D/A converter Voltage output -10 - 10V RL>2KΩ
Current output 4 - 20mA RL<350Ω
Zero output and full scale output can be digitally adjusted.
Zero adjusting range ：± 10%FS
Gain adjusting range ： ± 10%FS
Non-linearity ： 0.05%FS
Response ：Dependent on the A/D conversion
speed (2000 times/sec.) of the main
unit
