4.CALIBRATION
24
4-7.
Increment (This step may be
omitted if there is no change.)
Set the increment of the indicated value.
Input range: 001 -
100
How to set
1
）
Press the MODE button.
2
）
Press the CALIBRA
TION button.
3
）
Press the INCREMENT button.
4
）
Enter the
increment by th
e numerical key
s and determine wi
th the OK butt
on.
