1.APPEARANCE DESCRIPTION
4
1-2-1. AC Power Source Input Terminal Block
Connect the AC power cord. The input voltage is 100V - 240V AC, and the frequency is
50/60Hz.
1-2-2. Frame Ground (Functional ground)
This is a ground terminal block. Be sure to ground the F.G. terminal to prevent electric
shocks and failures due to static electricity.
1-2-3. Optional Slot
Any one of the following optional boards can be mounted.
• BCD data output F371
• D/A converter
• RS-485
• CC-Link interface
(CC-Link is an abbreviation for "Control & Communication Link".)
• Device Net interface
To Next Page
