9.WAVEFORM DISPLAY
72
9-2. Graph Plotting
9-2-1. Continuous
Graph plotting is start
ed by turning on the ST
AR
T/STOP key or turning on the ST/SP
external input. When it ends
on one screen, the screen is
cleared after expiration of the
interval time and graph plotting restarts on t
he next screen. It is ended by turning o
ff the
ST
AR
T/STOP key or turning o
ff the ST/SP external input.
t
＋
ST
ART/STOP
ST/SP
Sta
rt
Plotting P
eriod
（
Screen Hold
）
Plotting Period
X end point
X end point
Screen Clear
Interval Time
（
Key
）
（
Outside Input
）
time setteing
time settein
g
82
