9.WAVEFORM DISPLAY
75
9-3. Graph Function
Set the graph plotting mode.
Modes
Continuous, external, level, external + level
How to set
9-4. Interval Time
If you select "continuous" in the graph function setting, set the graph plotting operation
interrupting time from clearing the screen until moving to the next graph plotting
operation. During this time, the graph screen is held.
Setting range: 00.0 - 99.9 sec.
How to set
9-5. Graph Start Level
If you select [level] or [external + level] in the graph function setting, set the graph
plotting start level.
Setting range: -99999 - 99999
How to set
Setting call Page 1
→
→
Graph
Setting call Page 1
→
→
Graph
Setting call Page 1
→
→
Graph
