25.SETTING ITEM CHART
120
Setting of HOLD MODE（CH00 ～ CH15）
Setting of GRAPH（CH00 ～ CH15）
＊
The display position of a decimal point changes by the decimal point position setup in
the proofreading mode.
page Item Default
Calibration
LOCK
Set Value
LOCK
NS
1
１
Hold Function Tracking
◎
○
2 Hold Detect Time 1.000Sec
◎
○
3 Auto Start Level 00100*
◎
○
4 Minimum Count 010
◎
○
5 Valley Detect Level 1.0Times
◎
○
6
２
Minimum Slope 00030*
◎
○
7 Interval A 200
◎
○
8 Interval B 200
◎
○
9 Hold Point Shift 000
◎
○
10 Mean Value Sampling Count 001
◎
○
page Item Default
Calibration
LOCK
Set Value
LOCK
NS
1
１
Graph Function
CONTINUDE
◎
○
2 Interval Time 01.0Sec
◎
○
3 Graph Start Level 00100*
◎
○
4 Level Detet Mode
Passed High
◎
○
5 X Start Point 10.0Sec
◎
○
6
２
Y Start Point 00000*
◎
○
7 Y End Point 10000*
◎
○
