ArcLight Hub User’s Guide
Component Operating Procedures
Rev. 001 1081006 5-35
ports of the M&C are fully functional. In this case an Ethernet failure is
due to the self-test error. The M&C self-test is executed on every
chassis cold reboot. The M&C soft reboots which may occur from time
to time do not incur the M&C self-test.
After approximately 2 minutes, observe that all Alarm Panel Service
LEDs with corresponding modules installed are green, and the text
similar to
Figure 5-24 is displayed over the M&C management serial
port connection.
At the same time that the M&C is booting up the WAM is also booting
up and starting its operation. The WAM also has a management serial
port that can be connected using the same same cable that M&C
management serial port uses. This port is not interactive though and
can only be used to view the WAM execution trace. The WAM performs
its own self-test on every chassis cold boot. WAM cannot be soft booted.
Figure 5-23. ArcLight MCD Management Serial Port Power-up Self-Test Screen.
ViaSat, Inc./SBS Technologies, Inc. BIT Test Version 1.1
BIT TEST WILL START IN 8 SECONDS
Hit 'm' to select from menu
Hit 'ESC' to skip diagnostics
Starting BIT test..........
Testing SDRAM.........................128MB SDRAM
still testing SDRAM...............passed
Testing CPC710 registers..............passed
Testing socketed flash checksum.......passed
Testing NVRAM.........................passed
Testing PCI_ISA Resgisters............passed
Testing RTC...........................passed
Configuring Ethernet 1 for Self Test
Vendor ID : 12298086
Testing Ethernet 1....................failed
Configuring Ethernet 2 for Self Test
Vendor ID : 12298086
Testing Ethernet 2....................failed
Testing COM1..........................passed
Testing COM2..........................passed
Testing HASC........
HASC Version Register : 00000013..passed
HASC Abilities Register: 0000008F..passed
BIT TEST DONE
