ArcLight Hub User’s Guide
Component Operating Procedures
Rev. 001 1081006 5-89
Table 5-21. AHRFIU Input/Output Specifications (to be updated).
Frequency
Low
End
High
End
# Name Connector
Label (ohm)
Max RF
Power
Max DC
Power
(AMPs)
(MHz) (MHz)
1 Rx IN TNC (Female) Rx IN 50 +13dBm na DC 2150
2 Rx OUT BNC (Female) Rx OUT 50 +13dBm na DC 2150
3 Rx 10MHz IN BNC (Female)
Rx
10MHz IN 50 +13dBm na 10 10
4 Rx VDC Banana (Female) Rx VDC 0.75
Rx VDC Toggle Switch
ON / NC / ON
Toggle Switch 0.75
7 To Rx DownConverter (Primary) SMA (Female) OUT 1 (P) 50 +13dBm na 50 2150
8 To Rx DownConverter (Secondary) SMA (Female) OUT 1 (S) 50 +13dBm na 50 2150
9 From Rx DownConverter (Primary) SMA (Female) IN 1(P) 50 +13dBm na 50 2150
10
From Rx DownConverter
(Secondary)
SMA (Female) IN 1 (S) 50 +13dBm na 50 2150
11 To Rx HubCanceller (Primary) SMA (Female) OUT 2 (P) 50 +13dBm na 50 2150
12 To Rx HubCanceller (Secondary) SMA (Female) OUT 2 (S) 50 +13dBm na 50 2150
13 From Rx HubCanceller (Primary) SMA (Female) IN 2 (P) 50 +13dBm na 50 2150
14 From Rx HubCanceller (Secondary) SMA (Female) IN 2 (S) 50 +13dBm na 50 2150
15 Tx IN (Primary) SMA (Female)
Tx IN
Primary 50 +13dBm na DC 2150
16 Tx IN (Secondary) SMA (Female)
Tx IN
Secondary
50 +13dBm na DC 2150
17 Tx OUT N-Type (Female) Tx OUT 50 +13dBm na DC 2150
18 Tx 10MHz IN BNC (Female)
Tx
10MHz IN
50 +13dBm na 10 10
19 Tx VDC Banana (Female) Tx VDC 4
Tx VDC Toggle Switch
ON / NC / ON
Toggle Switch 4
22 To Tx HubCanceller (Primary) SMA (Female) Tx HC (P) 50 +13dBm na 50 2150
23 To Tx HubCanceller (Secondary) SMA (Female) Tx HC (S) 50 +13dBm na 50 2150
26 To Tx Up Converter (Primary) SMA (Female) OUT (P) 50 +13dBm na 50 2150
27 To Tx Up Converter (Secondary) SMA (Female) OUT (S) 50 +13dBm na 50 2150
28 From Tx Up Converter (Primary) SMA (Female) IN (P) 50 +13dBm na 50 2150
29 From Tx Up Converter (Secondary) SMA (Female) IN (S) 50 +13dBm na 50 2150
30 Leader VMBR IN (Primary) N-Type (Female)
Leader VMBR
Secondary
50 +13dBm na DC 2150
31 Leader VMBR IN (Secondary) N-Type (Female)
Leader VMBR
Secondary 50 +13dBm na DC 2150
32 Monitor Rx OUT TNC (Female)
Monitor
Rx OUT 50 +13dBm 0.75 DC 2150
33 Monitor Rx IN 1 TNC (Female)
Monitor
Rx 1
50 +13dBm 0.75 DC 2150
