No. Legend Description
Te Tip place For breakers only.
● 0: Trailing Edge will be centered depending on current
measured breaker width.
● 1: Trailing Edge will be centered depending on breaker
width parameter.
Logging ● 0: No logging.
● 1: Logging from material measurements and interface
commands to/from PLC.
Encoder inhibit
time
Minimum time between encoder values from Beckhoff BK5120
on the CAN network to VVS. By increasing the encoder inhibit
time, you can reduce the traffic on a CAN network.
The inhibit time is configured with a hexadecimal value and is
specified as follows:
● Encoder inhibit time = VVSConfig value (HEX) × 0.1 ms.
In case of problems, use the following values:
● 0x0A = 1 ms (default)
● 0x14 = 2 ms
Inhibit Le-Body Hold centering on transition from Leading End to Body.
Inhibit Body-Te Hold centering on transition from Body to Trailing End.
No material
counter
The number of camera scans needed for detection of no
material under camera.
History file size The centering history kept by VVS prior to overwriting the
conveyor files.
Dcom Active ● 0: Use a local OPC server.
● 1: Use a remote OPC server via DCOM.
No Delay ● 0: Normal operation.
● 1: For quick start-up to test a PC with no CAN network
attached.
Previous breaker
filter
● 0: The new breaker will be centered using the previous
breaker width.
● 1: The new breaker will be centered using the previous
three breakers widths to eliminate extremes.
IgnoreEncoder
WhenHolded
Ignore encoder pulses when the conveyor is in hold.
LoopedBack
HeartBeat
Instead of its own watchdog, VVS copies the watchdog
command bit from the PLC to the status buffer.
3 Device definitions
Device definitions are grouped per conveyor (Breaker1-4, Carcass, and Tread)
The CAN addresses must correspond with the address settings on the devices (For
more information, refer to the paragraph Addresses of all devices in the CAN
network on page 3
‑
15).
