7-14 OM EZ38 us 1.1 * ez38w700.fm
7
7.4 Maintenance accesses
Engine cover
Burn hazard due to hot engine parts!
Can cause severe injuries or death.
► Stop the engine and let it cool down.
► Wear protective equipment.
Personal injury hazard due to rotating parts!
Can cause severe injuries or death.
► Open the engine cover only at engine standstill.
Personal injury hazard due to open engine cover!
Can cause minor injuries.
► Take care not to knock your head on the open engine cover.
Opening:
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Open the engine cover by pressing button A.
The engine cover is supported by a gas strut.
Closing:
Firmly press down the engine cover.
Locking and unlocking:
The engine cover is locked with the starting key.
Turn the starting key in lock A clockwise to R.
➥ Engine cover locked.
Turn the starting key in lock A counter-clockwise to L.
➥ Engine cover unlocked.
