Refueling with a fuel-filling pump (option)
The filler inlet of the fuel tank is located on the left in the engine
compartment.
1. Stop and park the machine. Stop the engine. See “Preparing
lubrication”.
2. Open the engine cover.
3. Remove filler cap A.
4. Unwind hose B of the fuel-filling pump. The lance is located on the
right in the engine compartment.
5. Put the lance in the container with the fuel.
6. Switch on the fuel-filling pump with switch C.
7. The red LED D illuminates when the tank is full.
8. Switch off the fuel-filling pump with switch C.
9. Close filler cap A.
10.Close and lock the engine cover.
Fig. 243
A
Fig. 244
B
C
Fig. 245
D
