Adding hydraulic oil
1. Open the engine cover.
2. Open tank ventilation B to release the pressure.
3. Open filler plug C slowly.
4. Add hydraulic oil up to the corresponding mark.
5. Check the hydraulic oil level on sight glass A.
6. Add if necessary and check again.
7. Firmly screw filler plug C, and tighten tank ventilation B by hand.
8. Close and lock the engine cover.
Use a suitable container to collect engine/machine fluids as they flow out
and dispose of them in an environmentally friendly manner.
