Wacker Neuson EZ38 - Excavator Forces; Ground Clearance;Ground Pressure

9-12 OM EZ38 us 1.1 * ez38t900.fm
9
Excavator forces
According to ISO 6015
Ground clearance/ground pressure
EZ 38
Max. tearout force
(short stick)
17.8 kN (4,002 lbf)
Max. tearout force
(long stick)
15.8 kN (3,552 lbf)
Max. breakout force
at bucket tooth
32 kN (7,194 lbf)
EZ38 EZ38 VDS
Ground clearance 280 mm (11 in) 225 mm (9 in)
Ground pressure > 0.34 kg/cm² (4.8 lbs/in²)
Upper carriage rotation
speed
8.8 rpm
