OM EZ38 us 1.1 * ez38i400.fm 4-11
4
Seat adjustment
Accident hazard due to distraction when adjusting the seat!
Adjusting the seat during machine operation can cause severe injury or
death.
► Adjust the seat before putting the machine into operation.
► Ensure that the levers for seat adjustment are locked into place.
Weight adjustment
Injury hazard due to incorrect seat adjustment!
An incorrect weight adjustment can cause injuries to the spinal cord.
► Ensure that the seat is correctly adjusted to the operator’s weight
before traveling or operating the machine.
1. Sit down on the seat.
2. Turn lever A counter-clockwise.
➥ Adjusts a higher weight.
3. Turn lever A clockwise.
➥ Adjusts a lower weight.
Backrest adjustment
1. Sit down on the seat.
2. Pull lever B upward and lean back at the same time to push the
backrest into the required position.
3. Let lever B lock into place.
