Wacker Neuson EZ38 - Grab Control Circuit (Option); Stopping Grab Operation; Stopping Bucket Operation

5-36 OM EZ38 us 1.1 * ez38b510.fm
5
Grab control circuit (option)
Changeover is performed on either side of the stick.
Stopping grab operation:
1. Move both levers A on the ball-type cock to position B.
➥ Notch C indicates the flow direction.
Stopping bucket operation:
1. Move both levers A on the ball-type cock to position C.
Fig. 180
Fig. 181
B
A
C
Fig. 182
C
A
