OM EZ38 us 1.1 * ez38t900.fm 9-25
9
EZ38
A Height 2500 mm (98 in)
B1 Cabin width 990 mm (39 in)
B2 Upper carriage width 1600 mm (63 in)
B3 Travel gear width 1740 mm (68 in)
C1 Transport length (short stick) 4800 mm (15'-9'')
C2 Transport length (long stick) 4825 mm (15'-10'')
D1 Max. digging depth (short stick) 3110 mm (10'-2'')
D2 Max. digging depth (long stick) 3360 mm (11'-0'')
E1 Max. vertical digging depth (short stick) 2385 mm (94 in)
E2 Max. vertical digging depth (long stick) 2625 mm (8'-7'')
F1 Max. digging height (short stick) 4530 mm (14'-10'')
F2 Max. digging height (long stick) 4660 mm (15'-3'')
G1 Max. tilt height (short stick) 3320 mm (10'-11'')
G2 Max. tilt height (long stick) 3445 mm (11'-4'')
H1 Max. reach at ground level (short stick) 5190 mm (17'-0'')
H2 Max. reach at ground level (long stick) 5430 mm (17'-10'')
K1 Max. digging radius (short stick) 5300 mm (17'-5'')
K2 Max. digging radius (long stick) 5535 mm (18'-2'')
M Max. boom displacement to bucket center (right side) 740 mm (29 in)
N Max. boom displacement to bucket center (left side) 590 mm (23 in)
O Max. lift height of stabilizer blade over ground 380 mm (15 in)
P Max. scraping depth of stabilizer blade below ground surface 460 mm (18 in)
Q1 Distance between bucket and stabilizer blade (short stick) 260 mm (10 in)
Q2 Distance between bucket and stabilizer blade (long stick) 120 mm (5 in)
R1 Min. tail end swiveling radius 870 mm (34 in)
R2 Boom swivel radius (center) 2380 mm (94 in)
R3 Boom swivel radius (right) 2220 mm (87 in)
R4 Boom swivel radius (left) 1985 mm (78 in)
S Total running gear length 2060 mm (81 in)
T Running gear length (Turas front idler) 1605 mm (63 in)
W1 Max. tilting angle of boom to the right 55°
W2 Max. tilting angle of boom to the left 70°
X Track width 300 mm (12 in)
Y1 Stabilizer blade width 1740 mm (69 in)
Z Stabilizer blade height 355 mm (14 in)
