6. Mounting point for protective structure: B (lower).
7. Mounting point for cabin/canopy: C (upper)/D (lower).
8. Tighten lock nuts and screws E to 65 Nm (48 ft.lbs.).
9. Install the mirror in both positions F (option).
10.Install the light in position G (option).
Fig. 93
B
Fig. 94
C
D
Fig. 95
F
E
G
Fig. 96
E
