OPERATING AND OPERATION
99
WL50
12V
1 2
Fig. 44
Button for optional
hydraulics
1
2
Depressurized return line
For some attachments, a depressurized return line is re-
quired. The connection for the depressurized return line
is located on the front left of the load arm (Fig. 45). The
connection is designed in such a way that it is not possible
to confuse it with the normal connections for the optional
hydraulics.
Fig. 45
Depressurized
return line
