SERVICING AND INSPECTION
176
Servicing the water separator
Place a receptacle under the water separator Item 1
1.
(Fig. 79).
Unscrew the drain plug from the inspection glass Item 2.
a (Fig. 79).
The collected water now runs out.3.
Retighten the drain plug when the collected water has 4.
run out.
Venting the fuel system.5.
Fig. 79
Water separator
1
a
Fuel system
The fuel ltration system consists of a pre-lter (2) and a
main lter (3). The fuel is pumped by means of a feed pump
(F), which is anged to the engine block. The fuel lter as
well as the pre-lter and the feed pump are located on the
left-hand side of the engine.
Fig. 78
Position of the fuel
filters
2
3
F
