SERVICING AND INSPECTION
210
Servicing the electrical system10.7.12
WARNING
Electric shock hazard.
Always disconnect the battery before working
►
on the electrical system if tools, spare parts, etc.
with electrical components or contacts could
touch it.
Electric shock and burn hazards.
Do not clean sensitive electrical components
►
(instrument panel, alternator, compact plug,
multi-function lever, etc.) with a high-pressure
cleaner.
Do not touch incandescent lamps and headlight
►
reectors with your ngers if the bulbs have
been illuminated.
Have malfunctions in the electrical system cor-
rected by trained specialized personnel.
Fuse allocation
The electrical circuits of the wheel loader are fused to pre-
vent damage from short circuits and malfunctions. The fuses
are located in box 1 and 2 near the starting key receptacle
on the right side of the steering column. The second loca-
tion is on the right hand side of the cab next to operator‘s
seat (Fig. 101).
NOTICE:
If an electrical device fails to respond to a control
movement, stop the wheel loader as if stopping at
the end of a work shift and check the fuse for that
circuit. If the fuse has failed, determine the cause
of failure and repair the cause.
Insert a new fuse of the specied rating and return
to work.
Do not continue work with a failed fuse.
Do not install a fuse with a higher rated capacity
than the failed fuse. This can result in serious dam-
age to the electrical circuit.
