SERVICING AND INSPECTION
166
Tilting the operator’s platform
WARNING
Improperly tilting the cab can cause personal injury
or damage to equipment.
Before tilting the cab remove loose objects from
►
the cab to avoid control/indicator damage.
Close and conrm that the doors are latched ►
Do not attempt to tilt the cab until the wheel load-
►
er has cooled to the point that the engine and
hydraulic system are comfortable to touch.
Do not remove the bearing plate from the loader
►
rear frame member.
Do not operate the wheel loader until the cab
►
has been rigidly bolted to the main frame.
Tilt the cab slowly and keep hands and arms
►
clear of pinch points.
NOTICE:
Avoid damage to the cab doors.
Either close the doors or remove them.
Remove any loose objects from the operator’s plat-
1.
form.
Make sure there is sufcient room to the right of the
2.
loader.
Remove the two mounting bolts from the support bracket
3.
on the left of the operator’s platform (Fig. 72).
Close the cab doors.4.
Open the engine enclosure.5.
Remove the pump lever Item 1 (Fig. 73) from the holder
6.
and insert it in the opening in the hand pump Item 2
(Fig. 73).
Move the switch lever for the pump Item 3 (Fig. 73) to
7.
the right (arrow pointing upwards).
Now pump in order to tilt the operator’s platform.8.
