SERVICING AND INSPECTION
168
Lowering the operator’s platform:
Move the switch lever for the pump Item 3 (Fig. 73) to
1.
the left (arrow pointing downwards).
Put the pump lever Item 1 (Fig. 73) into the intended
2.
opening in the hand pump Item 2 (Fig. 73).
Release the locking of the operator’s platform safety
3.
supports by pulling the loop Item 1 (Fig. 74).
Now pump in order to lower the operator’s platform.4.
Re-install in the mounting bolts immediately after lower-
5.
ing the operator’s platform back in place.
Fig. 74
Cab safety support
1
