OPERATING AND OPERATION
93
WL50
Float position ( )
Press the multi-function lever Item A (Fig. 39) forward •
across the resistance until it engages:
The oat position engages. –
Pull back the multi-function lever Item A across the re-•
sistance:
The oat position disengages. –
Loader lift arms
Pull the multi-function lever Item A rearwards:•
The loader lift arms are raised. –
Pull the multi-function lever Item A forwards:•
The loader lift arms are lowered. –
Attachment
Pull the multi-function lever Item A to the left:•
The attachment curls upward for loading. –
Pull the multi-function lever Item A to the right:•
The attachment curls downward to dump. –
Fig. 39
Operating lever for
loader lift arms
A
