TECHNICAL DATA
41
WL50
Electrical system
The electrical system operates at 12 volts and the electrical
circuits are protected by fuses to prevent overload damage
to the system and its components.
Equipment
The loading equipment consists of the loader lift arms with
an integrated mechanical or hydraulic quick-change re-
ceptacle, lifting and tipping cylinders and the appropriate
attachments.
The loader is equipped with a rollover protective structure
(ROPS).
Loader data3.2
Engine
Manufacturer Deutz
Model 4-cylinder turbo diesel engine
Type TD 2011 L04 w
Capacity 3619 cm³ (221 inch³)
Cooling Water-cooled
Output
58 kW / 78 hp at 2300 rpm
SAE rating according to ISO9249
Drive (driving speed)
1. gear
0 – 7 km/h
0 – 4.35 mph
2. gear
0 – 20 km/h
0 – 12.43 mph
Steering
Fully hydraulic center-pivot steering
Rotating angle 12°
Turn angle 44°
