OPERATING AND OPERATION
106
For hydraulically activated attachments:
Screw the attachment‘s quick couplers to the appropri-
8.
ate connections of the attachment hydraulic lines on
the loader lift arms.
Check that there are no leaks in the attachment‘s hy-
9.
draulic system and the quick couplers of the attachment
hydraulic lines. Slowly actuate the attachment control
to conrm the controls are working correctly and the
couplers and hydraulic lines are not leaking.
Drive the loader up to the attachment (Fig. 48). 1.
Bring the locating pins Item 1 under the mounting hook
2.
Item 2.
Raise the loader lift arms and curl the attachment bracket
3.
to mate the coupler surface together.
Extend the locking pins Item 4 with the control lever for 4.
the optional hydraulics.
Check that both pins are engaged in the locking holes 5.
Item 3.
Press the »Relieve pressure« button (Fig. 48) to depres-
6.
surize the lines for the optional hydraulics.
Switch the three-way valve to »hydraulic connection«
7.
(Fig. 47).
